Solenoid, pilot and mechanical valves to ISO 5599/1.
– Mounting to ISO 5599/1.
– Full range: 1 – 2 – 3 – 4 size in 5/2 and 5/3.
– Mechanical system mixed(unique spool and poppet design) and spool.
– High capacity.
– Short internal stroke.
– High-tech body material.
– No lubrication required.
– Modular base.
– Mounting different sizes on the same sub-base possible.
Technical Data
Ambient temperature
‘-10 to +50 °C
Fluid temperature
Max +50 °C
Fluid
50 μm filtered air – Can be lubricated or not with spool system
Mechanism
Floating poppet system, spool system
Ways/Positions
5/2, 5/3
Pressure
10 bar max
Control
Return
Floating poppet system: air/mechanical spring
Spool system: air/mechanical spring or mechanical spring
Connections
ISO 5599/1 interface
size 1 size 2 size 3 size 4
Nominal Ø
8 10 15 19
Nominal flow rate (Nl/min)
1480 2300 4200 6600
Solenoid Pilot Valve
CNOMO U1 series
Coil
EC- series
Power Consumption
2.9 W (DC) – 5 VA (AC)
Voltage
12 V DC – 24 V DC – 24 V AC – 110 V AC – 230 V AC
Connector
AM 5111
Manual Override
2 position screwdriver operation (standard)
CONSTRUCTION DATA
Valve body
Acetal resin
Cover
Aluminium
Seals
Mixed system: nitrile rubber and polyurethane
Spool system: nitrile rubber
Sub-Base
Zinc alloy – aluminium
Actuators
Technopolymer
Spool
Aluminium
